| Model Number | 20 I | 25 I | 30 I | 35 I | 40 I |
| Spec Sheet | Spec Sheet PDF | Spec Sheet PDF | Spec Sheet PDF | Spec Sheet PDF | Spec Sheet PDF |
| Stress Chart | Stress Chart PDF | Stress Chart PDF | Stress Chart PDF | Stress Chart PDF | Stress Chart PDF |
| Above Ground Height | 20′ | 25′ | 30′ | 35′ | 39′ |
| Security Driver | Yes | Yes | Yes | Yes | Yes |
| Ground Sleeve Length | 3’x8″ | 3’x8″ | 3’x8″ | 4’x8″ | 4’x8″ |
| Overall Height | 23′ | 28′ | 33′ | 39′ | 43′ |
| Top Diameter | 3′ | 3′ | 3′ | 3′ | 3′ |
| Butt Diameter | 5.75′ | 6′ | 6.75′ | 7′ | 7′ |
| Gold Anodized Ball | 6′ | 6′ | 6′ | 8′ | 8′ |
| Truck | Cast FG Stationary Truck | Cast FG Stationary Truck | Cast FG Stationary Truck | Cast FG Stationary Truck | Cast FG Stationary Truck |
| Brass Snaps | 1 Pair | 1 Pair | 1 Pair | 1 Pair | 1 Pair |
| Vinyl Cover | 1 Pair | 1 Pair | 1 Pair | 1 Pair | 1 Pair |
| Ground Sleeve I.D. | 8” | 8” | 8” | 8” | 8” |
| Polyester Halyard | 40′ of #10 | 50′ of #7 | 60′ of #10 | 70′ of #10 | #10 |
| Flash Collar | 16′ | 16′ | 16′ | 16′ | 16′ |
| Pole Weight (lbs.) | 36 | 59 | 77 | 115 | 143 |
| Shipping Weight (lbs.) | 105 | 113 | 151 | 197 | 219 |
| Standard Flag Size | 4’x6′ | 4’x6′ | 5′ x 8′ | 5’x8′ | 6’x10′ |
