Vertical Wall Mount Flagpoles

Specifications and Accessories

Model NumberV 15V 20V 25V 30
Spec SheetSpec Sheet PDFSpec Sheet PDFSpec Sheet PDFSpec Sheet PDF
Stress ChartStress Chart PDFStress Chart PDFStress Chart PDFStress Chart PDF
Overall Height15’20’25’30’
Polyester Halyard40′ of #750′ of #760′ of #1070′ of #10
Top Diameter2.75”2.75”3”3”
Butt Diameter4”4”6”6”
Gold Anodized Ball5″5″6″8″
TruckCast FG Stationary TruckCast FG Stationary TruckCast FG Stationary TruckCast FG Stationary Truck
Brass Snaps1 pair1 pair1 pair1 pair
Vinyl Covers1 pair1 pair1 pair1 pair
Pole Weight (lbs.)6375106129
Shipping Weight (lbs.)**94107131172
Nylon Cleat8.5″8.5″8.5″8.5″
Bracket4” Alum.4” Alum.6” Alum.6” Alum.
Standard Flag Size4’x6′5’x8′5’x8′5’x8′

* Shipping weight includes weight of packaging and fittings.
