| Model Number | 50I | 60I | 70I | 80I |
| Spec Sheet | Spec Sheet PDF | Spec Sheet PDF | Spec Sheet PDF | Spec Sheet PDF |
| Stress Chart | Stress Chart PDF | Stress Chart PDF | Stress Chart PDF | Stress Chart PDF |
| Above Ground Height | 50′ | 60′ | 70′ | 80′ |
Retaining Ring | Medium | Medium | Large | Large |
| Ground Sleeve Length | 5’x14″ | 6’x14″ | 7’x21″ | 8’x 21″ |
| Overall Height | 55′ | 66′ | 77′ | 88′ |
| Halyard | S/S cable | S/S cable | S/S cable | S/S cable |
| Top Diameter | 4.5′ | 4.5′ | 7′ | 7′ |
| Butt Diameter | 10′ | 10.5′ | 16′ | 16.5′ |
| Gold Anodized Ball | 10′ | 10′ | 12′ | 12′ |
| Truck | Revolving Truck | Revolving Truck | Revolving Truck | Revolving Truck |
| Snaps | S/S | S/S | S/S | S/S |
| Cable | 1/8″ S/S Aircraft Cable | 1/8″ S/S Aircraft Cable | 1/8″ S/S Aircraft Cable | 1/8″ S/S Aircraft Cable |
| Ground Sleeve I.D. | 14” | 14” | 21” | 21” |
| Flag Arrangement | 1-8’x12′ | 1-10’x15′ | 1-12’x18′ | 1-12’x18′ |
| Flash Collar | 23′ | 23′ | 30′ | 30′ |
| Pole Weight (lbs.) | 325 | 480 | 807 | 1108 |
| Shipping Weight (lbs.) | 577 | 776 | 1336 | 1648 |
| Counterweight | Large | Large | Large | Large |
| Handle | Winch & Winch Handle | Winch & Winch Handle | Winch & Winch Handle | Winch & Winch Handle |
| Standard Flag Size | 8’x12′ | 10’x15′ | 12′ x 18′ | 12′ x 18′ |
