Nautical Double Masted
Flagpole with Yardarm/Gaff 50′-60′
| Model Number | NDM50- YAG | NDM60- YAG |
| Spec Sheet | Spec Sheet PDF | Spec Sheet PDF |
| Stress Char | Stress Chart PDF | Stress Chart PDF |
| Above Ground Height | 50’ | 60’ |
|
Burial Depth
|
6′ | 7′ |
|
Top Section
|
||
|
Length
|
21′ | 25′ |
|
Butt Diameter
|
8.5″ | 8.5″ |
|
Top Diameter
|
5″ | 5″ |
|
Standard Flags
|
8′ x 12′ | 8′ x 12′ |
|
Bottom Section
|
||
|
Length
|
37′ | 44′ |
|
Butt Diameter
|
10.9″ | 11.1″ |
|
Top Diameter
|
9.5″ | 9.5″ |
|
Yardarm
|
||
|
Length
|
16′ | 19′ |
|
End Diameter
|
3″ | 3″ |
|
Center Diameter
|
6′ x 10′ | 8′ x 12′ |
|
Gaff
|
||
|
Length
|
12.5″ | 15″ |
|
Tip Diameter
|
3″ | 3″ |
|
Standard Flags
|
8′ x 12′ | 8′ x 12′ |
|
Ground Sleeve
|
6′ x 14″ | 7′ x 14″ |
|
Gold Anodized Ball
|
10″ | 10″ |
|
Truck
|
Cast FG Stationary Truck | Cast FG Stationary Truck |
|
Gaff Truck
|
Cast Alum. Gaff Truck | Cast Alum. Gaff Truck |
|
Powder Coated Cleat
|
4 of 10″ | 4 of 10″ |
|
Polyester Halyard
|
4 of #12 | 4 of #12 |
|
Snaps (stainless steel)
|
4 pair | 4 pair |
|
Flash Collar
|
23″ | 23″ |
|
Pole Weight
|
417 | 867 |
|
Pole Weight (w/YA)
|
492 | 912 |
|
Shipping Weight
|
595 | 1075 |
|
Vinyl Covers
|
4 pair | 4 pair |
Yardarm & Gaff Brackets & Sticks (pre-assembled with S/S Eye-Bolts & Pulleys)
*Shipping Weight includes weight of packaging and fittings
